Security Filter

This stainless steel security filter is made of high-quality 304/316L stainless steel with excellent corrosion resistance, which can adapt to a variety of complex environments and ensure long-term stable operation. The main structure is compact and reasonable, and the top is equipped with a hanging ring for easy installation and maintenance. The precision filtration design can effectively intercept tiny particles, suspended solids and other impurities in the water, providing a pure guarantee for the subsequent process or water use, which is widely used in the field of water treatment, providing reliable pre-filter protection for the system and enhancing the stability and reliability of the overall system.

I. Product structure and principle

Product Mix:Stainless steel security filter has a shiny cylindrical appearance, and the main body is made of stainless steel, which has good metallic luster and corrosion resistance. The top is equipped with ring-shaped parts and bolt structure, which plays the role of stabilization and sealing. The interface on the side is convenient for connecting with other equipment to realize the inlet and outlet of fluids.
How it works:The fluid to be filtered enters the inside of the filter from the side interface, and when it passes through the internal filter element, the impurities, particles, etc. in it are intercepted by the filter element, while the clean fluid flows out through the interface on the other side, so as to achieve the purpose of filtration.

II. Performance Advantages

Excellent material: It is made of stainless steel, with strong corrosion resistance, adaptable to various complex working environments, and has a long service life.
High filtration accuracy: The internal filter element can be selected according to different needs, which can effectively intercept tiny particles and impurities and ensure the quality of the filtered fluid.
Reliable sealing: The ring component and bolt structure on the top ensures a good seal to prevent fluid leakage and improve filtration efficiency.
Convenient installation: The interface design on the side makes it easy to connect with other devices, reducing installation time and cost.

III. Application scenarios

Water treatment industry: As security filtration in the front end of reverse osmosis system, ultrafiltration system, etc., to protect the subsequent equipment from the damage of large particles of impurities.
Chemical industry: Used for the filtration of various chemical raw materials and solvents to ensure the purity and quality of products.
Food & Beverage Industry: Filtration of juices, milk and other liquids to remove suspended solids and impurities and to improve product taste and quality.
Pharmaceutical industry: Filtration of raw materials and intermediates during the production of pharmaceutical solutions to meet the high standards required for pharmaceuticals.

IV. Operation and maintenance

The operation is very simple, just connect the filter with the relevant equipment and turn on the fluid delivery. For maintenance, check the use of the filter element regularly and replace it in time when it is clogged or reaches the service life. At the same time, clean the appearance of the filter and keep its surface clean and tidy.

V. Technical parameters


Main material	304 or 316L stainless steel
Filtration accuracy	From 1μm - 100μm depending on the cartridge
work pressure	Maximum 1.0MPa - 2.5MPa (depending on model)
operating temperature	-20°C - 80°C (depending on seal material)
Interface Size	Available in DN25 - DN100 according to actual requirements.
Cartridge specifications	Adaptable to different lengths and diameters of cartridges
